| LED Lamp Specification |
| Color |
Package |
Intensity |
Viewing angle |
Wavelength |
Testing condition |
| Red |
3 IN 1 SMD |
70-100mcd |
140°/120° |
620-625nm |
25℃,20mA |
| Green |
120-200mcd |
140°/120° |
515-530nm |
25℃,10mA |
| Blue |
30-40mcd |
140°/120° |
465-475nm |
25℃,5mA |
| Module Parameter |
| Pixel Pitch |
P1.25mm |
| Pixel Strcture |
3 IN 1 SMD |
| Density |
640000pixels/㎡(real pixel) |
| Module Resolution |
256pixel(L) * 128pixel(H) |
| Module Dimension |
320mm(L) * 160mm (H) * 15mm(D) |
| Cabinet Dimension |
640*480*48.5mm |
| Cabinet Weight |
.68 (kg) |
|
| Single Point Brightness, Chroma Correction: Support |
| White Balance Brightness |
≥600 cd/㎡ |
| Viewing Angle |
140°(Horizontal)； 120°(Vertical) |
| Best Viewing Distance |
≥3m |
| Color Tempareture |
2000K-12500K (adjustable) |
| Display Color |
68.7 Billion Color |
| Brightness Uniformity |
≥97% |
| Contrast Ratio |
≥5000:1 |
| Process Performance |
| Single Processing bits |
16bits*3 |
| Gray Scale |
12-16Bit |
| Control Distance |
Cable:100m, Optical Fiber:10KM |
| Drive Mode |
Constant current source driver |
| Frame rate |
≥60Hz |
| Refress rate |
1920-3840Hz |
| Way to control |
Synchronize |
| Brightness adjustment range |
0-100 Stepless |
| Brightness Correction |
Pixel by pixel, module by module, cabinet by cabinet |
| User Paramiter |
| Working Temperature |
-20～+50 ºC |
| Stored Temperature |
-30～+60 ºC |
| Working Humidity |
10%～80% RH |
| Lifetime |
100,000 hours |
| MTBF |
5000 hours |
| Continuous Working Time |
≥72 hours |
| IP Protection Grade |
IP20 |
| Out of Control Pixel Rate |
≤0.01% |
