Description
MAPESEN MP-B306I302L-WTA2 Flashing Alarm WiFi SD Card PTZ Camera
MP-B306I302L-WTA2 Flashing Alarm WiFi SD Card PTZ Camera
PT Dome Camera with flashing alarm Camera • FULL color video 7/24 • H.264 / H.265 • 3.0MP • 30M IR Distance • Motion Detection Alarm with flashing lights • Audio Setting• Plug & Play onvif Compatibity •IP67 • We offer a range of series with different shapes, resolutions and lens to fulfill different demands.
FEATURES:
- WIFI SD Card PT Dome Camera(Fix Lens)
- Wireless standards: IEEE802.11b/g/n
- 360 degree auto-cruise
- FULL color video 7/24,30M HD face recording at night time
- Support voice intercom, Built-in speaker & Microphone
- Storage : 1 TF(Micro SD)storage interface,Max128G
- Support AP Hotspot/Broadcast/Scanning QR code AP
SPECIFICATIONS:
| Model | MP-B306I302L-WTA2 |
| Camera | |
| Image Sensor | 1/2.7″ color CMOS |
| Effective Pixels | 3.0MP/1080P |
| Synchronization | Internal |
| Code Format | H265/H264 |
| Code Rate | 32Kbps~6144Kbps adjustable, default 1536kbps |
| Stream | Dual-stream |
| Frame Rate | Main code stream:3MP (2304X1296)@20fps |
| Auxiliary stream:800×448@20fps | |
| Min. Illumination | 0.1LUX/F1.2 color,0.01LUX/F1.2 WITH IR ON (BW) |
| Day & Night Mode | Color/B&W/Intelligent model |
| Electronic Shutter | Auto |
| White Balance | Auto |
| AGC | Auto |
| WDR | Digital WDR |
| DNR | 3D DNR |
| SNR | ≥48dB |
| IR board | 6PCS IR Array LEDs (4pcs IR LEDs,2pcs white LEDs) |
| IR Distance | 30m IR distance,10m white colorful vision distance |
| PTZ | |
| Horizontal Angle | 0-355° |
| Vertical Angle | 0-90° |
| Pan Speed | 0.1°-20°/S |
| Tilt Speed | 0.1°-20°/S |
| Preset Point | 7 preset points |
| cruise | Support |
| Functions | |
| Motion Detection | Support |
| Snapshot | Support |
| Email Alarm | Support |
| Audio Setting | People can make your voice record and automatically to tell the people who break into your area |
| Detection Alarm | When Detected people around, blue & red strobe flashing with audio |
| Alarm linkage | The mobile detection alarm is pushed to the APP Or device local sound alarm |
| Mirror Image | Flip horizontal/vertical |
| Voice Intercom | Built-in microphone and speaker |
| Storage | Built-in Micro SD card slot, Max128G, timer capture |
| Web Access | Support IE, Google, Firefox browser, Built-in webserver to facilitate the user to use the standard IE browser to achieve the front end of the real-time browsing and setting management |
| Lens | |
| Focal Length | 3.6mm fix lens |
| Lens Megapixel | 3 Megapixel fixed lens |
| NETWORK | |
| Network Interface | 1*RJ45 10M/100M Ethernet Port |
| WIFI | WIFI 802.11b/g/n |
| AP | Support |
| P2P | Support Max 6users, browsing at the same time (each stream: 3 users) |
| Mobile Surveillance | iOS, Android |
| PC | Support |
| Interface | |
| Antenna | 1 * WIFI |
| Storage | 1PC Micro SD card |
| Reset | Support key reset |
| Ethernet | 1PC RJ45 |
| General | |
| Working Temperature | -30 °C to [$add]60 °C |
| Working Humidity | 10%-90% RH (Non-condensing) |
| Power Supply | DC12V2A |
| Lightning protection | GB/T17626.5, IEC61000-4-5 |
| Power Consumption | Max 10W |
| Housing | Outdoor Metal Bullet |
| Weather Proof | IP67 |
| Size | 22.6*19.0*13.3 cm |
